RC-Series Single-Acting Hydraulic Cylinder Bearing Capacity 142KN
Technical data
Type |
Carrying capacity (KN) |
stroke mm |
Outside diameter mm |
height mm |
weight kg |
RC-151 |
142
|
25 | 69 | 124 | 3.5 |
RC-152 | 51 | 69 | 149 | 4.4 | |
RC-154 | 101 | 69 | 200 | 5.3 | |
RC-156 | 152 | 69 | 271 | 7 | |
RC-158 | 203 | 69 | 322 | 8.4 | |
RC-1510 | 254 | 69 | 373 | 9.7 | |
RC-1512 | 305 | 69 | 423 | 11 | |
RC-1514 | 356 | 69 | 474 | 12 |
Notice
1. High temperature sealing is optional
2. The data in the above table is subject to deviation and is for reference only. Subject to actual data.
Think Safety
Manufacturer’s rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!
