HDFD1100 Digital Display Marine Fuel Valve Test Device

1 set
MOQ
Negotiate
Price
HDFD1100 Digital Display Marine Fuel Valve Test Device
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Fuel Valve Test Device
Model: HDFD1100
Drive Way: Pneumatic
Display Mode: Digital Display
N.W.: 77Kg
G.W.: 100Kg
AIR ACCESS PORT: ISO228/1-G1/2
HIGH-VOLTAGE OUTPUT: ISO228/1-G1/4
Highlight:

77Kg Fuel Valve Test Device

,

12Ltr/cycle Pneumatic Fuel Valve Test Device

,

diesel engine tester 700x450x1120mm

Basic Infomation
Place of Origin: China
Brand Name: AI LE SEN
Certification: ISO9001
Model Number: HDFD1100
Payment & Shipping Terms
Packaging Details: Cardboard box
Delivery Time: In stock
Payment Terms: D/P, T/T
Supply Ability: 100 Set Every month
Product Description

                             HDFD1100 Digital Display Marine Fuel Valve Test Device

Product Brief

use:The pump unit, mainly used to measure its spray condition, is an essential test tool for high-power diesel engines.

Advantage:

1. It has the advantages of big power

2. Wide scope of application: coversLow Speed Diesel Engine.B&W35-98

3. Use digital acquisition system to be more accurate

4. Stainless steel shockproof pressure gauge



Technical parameter

Output pressure

Max.80MPa at 0.7MPa air input

Air consumption

12 Liters/cycle at 0.7MPa air input

Max. flow of fuel oil

40ML/cycle at an air input of 0.4Mpa

Pumping speed

30cycle/Min at 0.4MPa air input (no output pressure)

Tank capacity

8L

Dimension

700x450x1120mm

Weight

77kg



Random configuration list

Name Quantity
Spare parts for fuel valve clamping 1 Set
Repair kits 1 Set



Purchase Notes:Please inform us the main diesel engine model, such as 7G80MEB

Means of transaction:Pay first and ship(FOB)

If you need to buy a fuel valve test device, please contact us directly, because we are a professional manufacturer. No matter whether the price or technology will benefit you the most .

HDFD1100 Digital Display Marine Fuel Valve Test Device 0

HDFD1100 Digital Display Marine Fuel Valve Test Device 1

HDFD1100 Digital Display Marine Fuel Valve Test Device 2



HDFD1100 Digital Display Marine Fuel Valve Test Device 3





  Common faults and troubleshooting

1) The pressure cannot be built up:
1. Check whether the nut of the injector fixing screw is tight (compression nut).
2. Check whether the test oil meets the hydraulic oil specified in this manual (replace the specified oil).
3. Check whether the filter is cleaned according to the specified time (replace and clean the oil filter).
4. Check whether the oil level of the fuel tank is too low (add test oil).
2) The test bench does not work:
1. Check whether the air pipeline connected to the test bench is unblocked (replace the joint and the air pipe).
2. Check whether the air pressure regulating valve (3) and the input air meter (6) have air pressure (replace the air pressure regulating valve).
3) Pressure leakage:
1. Check whether there is any leakage in the joints inside the test bench (tighten the joints).
2. Check whether the oil return valve leaks (grind the oil return valve stem, replace the oil return valve).
3. Check the input and output joints of the high-pressure oil pump for oil return (disassemble the two joints to clean or replace the two inlet and outlet joints).
4) The pressure gauge does not return to zero when the pressure is zero:
After the pressure on the test bench is completely released, adjust the "0-adj" knob at the back of the digital display to return to zero. Increase in clockwise direction and decrease in counterclockwise direction. (If there is no response, replace the pressure gauge and pressure sensor).
5) The digital display meter does not display:
1. Check the power input terminal of the digital display meter (terminal 1, 2 is 110VAC; terminal 1, 3 is 220VAC. Choose which group of inputs according to the situation on board, please consult the electrical engineer on board).
2. Check whether the input terminal has electricity, if there is electricity, it will not display (replace the digital display meter.)
6) Garbled characters on the digital display:

Replace the pressure sensor if it is still garbled, please replace the digital display

For information about Fuel Valve Test Device, Please E-mail :ailesen@163.net

Company website:www.aileseng.com
